Quark-Elec AS13 2G/3G/4G outdoor Omni Antenna

Brands:
Articlenumber: AS13 Categories: , , Brands:

€ 69,00

Availability: In Stock
  • Compact antenna
  • Suitable for 4g
  • GPS-enabled
  • Including 10m cable
Status In stock
Articlenumber: AS13 Categories: , , Brands:

Beschrijving

The AS13 is the perfect 2G/3G/4G mobile signal antenna for small to medium-sized sailboats and powerboats.

The antenna is designed for maximum flexibility with multiple carriers for harsh environments. The polyurethane-coated fibre-optic antenna provides a reliable and robust solution for maritime and offshore environments. The AS13 antenna covers 2G, 3G and 4G systems for GSM, DSC, WCDMA and LTE frequencies. The omnidirectional design provides 360° reception with a range of up to 22 miles

The AS13's operating frequency band covers the GPS frequency (1575 MHz) and can be used as a passive GPS antenna or as a multiplexed cellular + GPS antenna.



Optional with 4-way antenna base and SMA to N connector (for use with R042 Router)

  • Polyurethane-coated fibreglass
  • Frequency: 800 - 2600 MHz, compatible with most 2G (GSM / GPRS) / 3G (UMTS) / 4G (LTE) networks
  • Impedance: 50 Ω
  • VSWR: <1.5:1 V
  • Amplification: 5.5-8 dBi
  • With 10m coaxial cable
  • 0.6-metre fibreglass antenna
  • Polyurethane coated
  • Frequency Range: 800- 2600 MHz
  • Impedance: 50 Ω
  • Dimensions (mm): Փ20 x L660
  • Gain: 5.5-8.0 dBi
  • Antistatic protection: Direct ground
  • VSWR: <1.5:1
  • Maximum input power: 50W
  • Polarization: Vertical
  • Weight of antenna including 10m coaxial cable: 0.65 Kg
  • Operation Temperature: -40℃ to +80℃
  • Wind Speed Tolerance: 55m/s (125mph)
  • SMA (male) Connector
  • Chrome-plated brass ferrule with standard 25mm/1 inch-14 thread
  • IP67 Waterproof
  • 10 metres/15′ RG58 A/U coaxial cable included

Additional information

Shipping time

3 days

Brand

Quark-Elec
